Door Frame Metal Machine by Roll Forming |
| Item | Specification |
| Material | Type | galvanized steel sheet |
| Thickness(mm) | 0.8 -1.2 |
| Yield strength(mpa) | 235 -345 |
| Roller material | 45#Chrome steel |
| Forming speed(m/min) | About 10m/min |
| Speed adjusting mode | AC Frequency |
| Roller drive | Decelerating motor + Chain drive |
| Cutting mode | Hydraulic cutting |
| Cutter material | Cr12 mold steel |
| Length measurement | Encoder |
| Control mode | Mitsubishi PLC |
| Operating mode | Button + Mitsubishi Touch screen |
| Main motor power(kw) | 15 KW (Depend on final design) |
| Hydraulic station power | 5.5 K W (Depend on final design) |
| Total power(kw) | 20.5 KW |
| Uncoiler's loading capacity | Max. Capacity: 3000kgs |
| Machine weight | About 7000kgs |
| Machine size | About 8*1.3*1.5m (Depend on final design) |
| Components of machine: |
| Decoiler | 1set |
| Feeding & guiding device | 1set |
| Main roll forming machine | 1set |
| Punching equipment | 1set |
| Hydraulic cutting system | 1set |
| PLC Controlling system | 1set |
| Run out table | 1set |
Process flow:
Decoiling the sheet → Leveling sheet→Punching → Roll forming→
Measure length and cutting→ the Product to the supporter |
