    CE Certificated Double Layer Roll Forming Machine 4 Kw Hydraulic System.

    Ask Lasest Price
    Brand Name : ZBR
    Model Number : ZBR-b-103
    Certification : CE, SGS, ISO9001
    Price : Negotiated
    Payment Terms : Negotiated
    Supply Ability : 10 sets per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    CE Certificated Double Layer Roll Forming Machine 4 Kw Hydraulic System.

    CE Certificated Double Layer Roll Forming Machine 4 Kw Hydraulic System.


    Product Description


    Double layer roll forming machine with the capable of forming a limited site area in two sections, and can quickly transform products, affordable, can be the perfect combination of the two models of devices into one, two plate replacement time becomes shorter, and also improve the rate of output.


    Manual Un-coiler

    ◊ Max Capacity: 5000kgs

    ◊ Inner diameter of coil: 400-600mm

    ◊ Manual with brake

    Leveling Device

    ◊ Ensure the material level and straight
    ◊ The width can be adjusted

    Auto Main Forming System

    ◊ Max Feeding width:1220 mm
    ◊ Product width: 1000 & 1020 mm
    ◊ Thickness of sheet: 0.2-1.0mm
    ◊ Motor Power: 5.5 kw forming system
    ◊ Roller material: C45 steel
    ◊ Diameter of shaft: Upper level 95 mm Down level 95 mm
    ◊ Forming station: Upper level 12 stations. Down level 12 stations.
    ◊ Base Frame: 360 H steel welded..

    Hydraulic Cutting Device

    ◊ Cutting way: pause to cut.
    ◊ Oil pump station 1set.
    ◊ Hydraulic power: 4 kw hydraulic system.
    ◊ Blade Material: CR12 with heat treatment HRC60-62.

    Electrical System

    ◊ Control system: HMI & PLC control panel.
    ◊ Power: 440V 50Hz (as per local requirement)

    Run-out Table

    ◊ Frame: 8# steel groove welded
    ◊ Roller type.
    ◊ Quantity: 1 pc


    Working flow:
    Decoiler----- feeding ------roll forming ------ cutting----output table

    Machine components:

    De-coiler------------------------------------------1set

    Forming machine------------------------------1set

    Cutting device -----------------------------------1set

    Punching device---------------------------------1set

    PLC control box ---------------------------------1set

    Hydraulic pump station------------------------1set

    Production support table----------------------1set
